Anilam
Scales:
Obsolete
Scales: A10, C10, D10, KM10, MBT = 10 Micron went
to
RBS 10
SST/MBT = 10 Micron (Mini scale) went to
RBM-10T
with adapter
B1, E1 = 1 Micron went to
RBS 1
A2, C2, F2 = 2 Micron went to
RBS 2
B5, E5, KM5 = 5 Micron went to
RBS 5
PGSP-E,
PGSP-P = 5 Micron went to
PGSP-T
New Replacement scales for PGSP, RBS, and RBM
Replacement scale For Crusader II or M, Z axis down feed 4 inch
Pgsp-E or P Part Number series was 198YXXXX (Were only 5 micron
resolution!)
Note: XXXX = the travel of the axis. For example 19800036 = a 36”
travel scale with a round connector on the end of the cable.
The Y location when there is a 0, it has a round connector when it has a 1
in this location there is a DE9 connector on the cable.
Pgsp-T Part Number series is 198YXXXX (Were only 5 micron
resolution!)
Note: XXXX = the travel of the axis. For example 19810036 = a 36”
travel scale with a DE9 connector on the end of the cable.
The Y location when there is a 0, it has a round connector when it has a 1
in this location there is a DE9 connector on the cable.
RBM-5T Part Number series is 20705XX (Were only 5 micron
resolution!)
Note: XX = the travels of the axis. For example 2070502 = a 2
inch travel scale with a DE9 and the 05 number represents the
resolution of 5 MICRON.
RBM-1T Part Number series is 20701XX (Were only 1 micron
resolution!)
Note: XX = the travels of the axis. For example 2070102 = a 2”
travel scale with a DE9 and the 01 number represents the resolution
of 1 MICRON.
RBM-10T Part Number series is 20310XX (Were only 10 micron resolution!)
Note: XX = the travels of the axis. For example 2031002 = a 2”
travel scale with a DE9 and the 10 number represents the resolution
of 10 MICRON.
RBS
Note: 201 and 202 series Has round 6 pin connector.
205 series has a DE9 connector.
Here is an example of what the part numbers mean:
201YYXXX, where the YY = the resolution, and the XXX = the travel.
201 series like 20110012 = 12 inch RBS 10 scale with round
connector and either 13’ or 19’ cable.
20102XXX
RBS 2 scales (Were
only 2 micron resolution!)
20110XXX
RBS 10 scales (Were only
10 micron resolution!)
20210XXX series like 20210010 = 10 inch RBS
10 scale with round
connector and 12” of cable.
20201XXX series like 20201012 = 12 inch RBS-1T scale with D9
connector and 12” of cable.
205 series like 20501006 = 6 inch RBS 1 scale with DE9 connector
and either 13’ or 19’ cable.
20501XXX
RBS 1T scales (Were only
1 micron resolution!)
OBSOLETE click Here to see new scales!
20505XXX
RBS 5T scales (Were only
5 micron resolution!)
OBSOLETE click Here to see new scales!
ENC 250 (PTS 250)
