Program Directory Parameter

Function

Settings

Program directory pattern

Type of programs displayed.

*.M (program file extension)

NOTE: Do not change this parameter.

 Program directory display mode

Specifies the program information to display in the Program Directory.

Short Filename and extension only. [Default]

Long Detailed program information, including file size, etc.

 Program directory sort order

Specifies order in which program are listed in the Program Directory.

Ignore CNC ignores parameter.

Name Alphanumeric order by filename. [Default]

Extension Alphanumeric order by extension.

Size By file size.

Date By date program was created.

 Automatically check disk at startup

For machines equipped with hard drives, specifies whether and how often CNC will check the hard drive.

NOTE: Disk Check is not available under any Windows operating system. If you select it, the CNC displays a message to inform you that the feature is disabled.

Always

Daily

Weekly [Default]

Monthly

Never

 Delete backup files during optimize

Specifies whether to delete backup files during hard drive optimization.

NOTE: Disk Optimization is not available under any Windows

operating system. If you select it, the CNC displays a message

to inform you that the feature is disabled.

Yes Backup files deleted during optimization process. [Default]

No Backup files maintained during optimization process

 Directory for user programs

CNC will store user programs in specified directory.

C:\USER [Default]

Type user directory location.
