Edit Mode Parameter

Function

Settings

Create backup program

The CNC creates a backup program that it updates each time you edit the program. The backup program will not contain an edit until you make a new edit.

Yes Creates and maintains a backup program.

No No backup programs are created. [Default]

Delete internal file when program saved

When the program is saved, the CNC automatically deletes the existing internal file (*.S files) and replaces it with the saved file.

Yes Deletes internal file when you save a file and replaces it with an updated file. [Default]

No CNC does not delete internal file when the user saves a program

Case sensitive Find

Determines whether the Find feature will look for uppercase letters and lowercase letters to determine a match.

Yes Find search parameter looks for words that match the typed word exactly regarding capitalization and style.

No Find search parameter looks for typed word regardless of capitalization and style. [Default]

Memory reserved from Editor (in K-bytes)

Specifies maximum memory allocation for the Editor.

300 [Default] Type a value.
