Communications Parameter

Function

Settings

Port

Select communications port (COM1) or disable. Must enable to perform DNC or other remote communications

COM1

COM2 [Default]

Disabled

Baud

Select baud

110

150

300

600

1200

2400

4800

9600 [Default]

19,200

Parity

Select parity

Odd

Even [Default]

None

Data bits

Type number of data bits

7 [Default]

8

Stop bits

Type number of stop bits

0

1 [Default]

Software

Refers to XON or XOFF or software handshaking (transmission/receipt of data via RS-232 channels) in

commercial communications packages.

On Enables handshaking. [Default]

Off Disables handshaking
